Male Connector Fittings
Jergens Male Connector Fittings are a type of plumbing fitting that is used to connect pipes or tubes. They are typically used to connect a pipe or tube to a female fitting or valve. The male connector has a male thread on one end and a barbed end on the other that can be inserted into a tube or hose. The male thread can be connected to a female fitting, valve, or other types of connection.
Features, Benefits, & Product Specifications:
-
Easily installed & removed
-
Secure connection
Documents
Male Connector Fittings
Select a part number for CAD drawings, price and stock availability.
| Part Number | CAD | Unit | Thread | Tube |
|---|---|---|---|---|
| 61007 |
|
Inch | Pipe | 1/8 NPT x 1/4 Tube |
| 61008 |
|
Inch | Pipe | 1/4 NPT x 1/4 Tube |
| 61009 |
|
Inch | Straight | 7/16-20 x 1/4 Tube |
| 61020 |
|
Inch | Pipe | 1/4 NPT x 3/8 Tube |
| 61021 |
|
Inch | Straight | 9/16-18 x 3/8 Tube |
| 61028 |
|
Inch | Pipe | 3/8 NPT x 1/4 Tube |
| 61030 |
|
Inch | Straight | 9/16-18 x 1/4 Tube |
| 61034 |
|
Inch | Pipe | 3/8 NPT x 3/8 Tube |
| 61046 |
|
Inch | Straight | 3/4-16 x 3/8 Tube |
| 61048 |
|
Inch | Pipe | 3/8 NPT x 1/2 Tube |
| 61054 |
|
Inch | Pipe | 1/8 NPT x 3/8 Tube |
